FWD Diesel Engine with Gearbox Cutaway
This cutaway model is carefully sectioned for training purposes, professionally painted with different colours to better differentiate the various parts, cross-sections, lubricating circuits, fuel system, cooling system etc. Many parts have been chromium-plated and galvanised for a longer life.

Other Available Cutaway Models:
Specifications:

Main Technical Specifications:
  • 4 stroke engine
  • 4 in-line cylinders
  • Displacement: 1300 cc
  • Indirect injection
  • VE Bosch type rotary injection pump
  • Overhead camshaft (OHC)
  • Distribution through a toothed belt
  • Alternator
  • Thermostatic valve
  • Power: 45 hp.
  • Gearbox: 5 forward speeds + reverse and differential
  • Single-plate clutch with diaphragm

Other Specifications:
  • Operated: Manually (Through a Crank Handle)
  • Equipment Layout: On Stand with Wheels
  • Dimensions: 130 x 86 x 100(h) cm
  • Net Weight: 140 kg
  • Gross Weight: 200 kg
Product: FWD Diesel Engine with Gearbox Cutaway
Product Code: VB 6068M
