Multipoint Electronic Fuel Injection V6 DOHC Petrol Engine Cutaway
This cutaway model is carefully sectioned for training purposes, professionally painted with different colours to better differentiate the various parts, cross-sections, lubricating circuits, fuel system, cooling system etc. Many parts have been chromium-plated and galvanised for a longer life.


Other Available Models:
  • Multipoint EFI V6 DOHC Petrol Engine (Electrically Operated) Cutaway – (VB 5195E)

  • Carburettor V6 OHC Petrol Engine (Manually Operated) Cutaway – (VB 5190M)
  • Carburettor V6 OHC Petrol Engine (Electrically Operated) Cutaway – (VB 5190E)
    Specifications:

    Main Technical Specifications (VB5195):
    • 6 V cylinders
    • Displacement: 2000-3000 cc
    • DOHC (2 per head)
    • Multi-point E.I.
    • Centrifugal water pump
    • 12V alternator
    Other Specifications:
    • Operated: Manually (Through a Crank Handle)
    • Equipment Layout: On Stand with Wheels
    • Dimensions: 120 x 60 x 100(h) cm
    • Net Weight: 190 kg
    • Gross Weight: 260 kg

    Main Technical Specifications (VB5190):
    • 6 V cylinders
    • Displacement: 2800/3200 cu. cm
    • Overhead camshaft OHC (1 per head)
    • Twin-body carburettor
    • Centrifugal water pump
    • 12 Volt alternator
    • Membrane clutch
    Other Specifications:
    • Operated: Manually (Through a Crank Handle)
    • Equipment Layout: On Stand with Wheels
    • Dimensions: 120 x 60 x 100(h) cm
    • Net Weight: 190 kg
    • Gross Weight: 260 kg
    Product: Multipoint Electronic Fuel Injection V6 DOHC Petrol Engine Cutaway
    Product Code: VB 5195M
